Bouchon obturateur taraudage SAE et NPT

 +33 (0)1-82-88-58-31


Bouchon obturateur taraudage SAE et NPT

PIP


Bouchon clipsable taraudage SAE/NPT
Bouchon obturateur taraudage SAE et NPT

PIP–Médias

Taraudages NPT et SAE Bouchon enfichable pour Taraudages NPT et SAE Bouchon obturateur pour filetages SAE Bouchon obturateur pour filetages NPT Bouchon enfichable pour filetages SAE ou NPT Bouchon clipsable taraudage SAE/NPT Bouchon plastique clipsable taraudage SAE/NPT Bouchons filetés à pose facile Bouchon pression Bouchon obturateur taraudage SAE et NPT
  • Matière : PE-BD (Polyéthylène basse densité) (Rouge)
  • Protection interne de traudage en un simple clic

Tableau de mesures Bouchon obturateur pour filetages SAE

PIP Tableau de mesures

Vue de tableau
Affichage de liste
Référence Description Filets NPT SAE... Diamètre
mm
po
Longueur
mm
po
Ø coll.
mm
po
Boite/Minipack/Protopack
Qté
Voir prix / Acheter
PIP0250RD1 Bouchon obturateur taraudage SAE et NPT - PUSH IN PLUG FOR 1/4 SAE THRDS, LDPE RED 1/4"
5.2
0.206
5.6
0.220
11.5
0.452
5000 1000 100
PIP0313RD1 Bouchon pression - PUSH IN PLUG FOR 5/16 SAE THRDS, LDPE RED 5/16"
6.7
0.262
6.0
0.235
13.4
0.527
5000 1000 100
PIPL0375RD1 Bouchons filetés à pose facile - PUSH IN PLUG LONG FOR 3/8 SAE OR 1/8 NPT THRDS, LDPE RED 1/8" 3/8"
7.9
0.310
8.6
0.340
14.9
0.588
5000 1000 100
PIP0375RD1 Bouchon plastique clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 3/8 SAE OR 1/8 NPT THREADS LDPE RED 1/8" 3/8"
8.2
0.324
6.0
0.235
14.9
0.588
5000 1000 100
PIP0438RD1 Bouchon clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 7/16 SAE THRDS, LDPE RED 7/16"
9.7
0.380
6.9
0.270
16.7
0.656
5000 1000 100
PIP0500RD1 Bouchon enfichable pour filetages SAE ou NPT - PUSH IN PLUG FOR 1/2 SAE OR 1/4 NPT THRDS, LDPE RED 1/4" 1/2"
11.1
0.437
6.9
0.270
18.4
0.724
5000 1000 100
PIPL0563RD1 Bouchon obturateur pour filetages NPT - PUSH IN PLUG LONG FOR 9/16 SAE THRDS, LDPE RED 9/16"
12.2
0.480
9.1
0.360
21.2
0.835
5000 1000 100
PIP0563RD1 Bouchon obturateur pour filetages SAE - PUSH IN PLUG FOR 9/16 SAE THRDS, LDPE RED 9/16"
12.6
0.495
7.4
0.290
20.6
0.810
5000 1000 100
PIP0625RD1 Bouchon enfichable pour Taraudages NPT et SAE - PUSH IN PLUG FOR 5/8 SAE OR 3/8 NPT THRDS, LDPE RED 3/8" 5/8"
14.2
0.558
7.4
0.290
24.7
0.971
5000 1000 100
PIP0688RD1 Bouchon obturateur taraudage SAE et NPT - PUSH IN PLUG FOR 11/16 SAE THRDS, LDPE RED 11/16"
15.5
0.610
7.4
0.290
25.6
1.008
5000 1000 100
PIP0750RD1 Bouchon pression - PUSH IN PLUG FOR 3/4 SAE THRDS, LDPE RED 3/4"
17.2
0.676
7.4
0.290
26.5
1.045
5000 1000 100
PIP0813RD1 Bouchons filetés à pose facile - PUSH IN PLUG FOR 13/16 SAE OR 1/2 NPT THRDS, LDPE RED 1/2" 13/16"
18.6
0.732
7.4
0.290
27.8
1.094
5000 1000 100
PIP0875RD1 Bouchon plastique clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 7/8 SAE THRDS, LDPE RED 7/8"
20.3
0.798
7.5
0.295
29.8
1.172
4500 900 90
PIP1000RD1 Bouchon clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 1 SAE OR 3/4 NPT THRDS, LDPE RED 3/4" 1"
23.4
0.922
7.4
0.290
33.1
1.305
3500 700 70
PIP1062RD1 Bouchon enfichable pour filetages SAE ou NPT - PUSH IN PLUG FOR 1-1/16 SAE THRDS, LDPE RED 1-1/16"
24.7
0.972
7.4
0.290
36.0
1.417
3000 600 60
PIP1188RD1 Bouchon obturateur pour filetages NPT - PUSH IN PLUG FOR 1-3/16 SAE THRDS, LDPE RED 1-3/16"
27.7
1.090
8.6
0.340
38.6
1.518
2000 400 40
PIP1250RD1 Bouchon obturateur pour filetages SAE - PUSH IN PLUG FOR 1-1/4 SAE THRDS, LDPE RED 1-1/4"
29.5
1.160
8.6
0.340
39.9
1.571
2000 400 40
PIP1313RD1 Bouchon enfichable pour Taraudages NPT et SAE - PUSH IN PLUG FOR 1-5/16 SAE OR 1 NPT THRDS, LDPE RED 1" 1-5/16"
30.9
1.215
8.6
0.340
41.7
1.640
2000 400 40
PIP1438RD1 Bouchon obturateur taraudage SAE et NPT - PUSH IN PLUG FOR 1-7/16 SAE THRDS, LDPE RED 1-7/16"
34.5
1.360
11.7
0.460
45.8
1.803
1200 240 24
PIP1500RD1 Bouchon pression - PUSH IN PLUG FOR 1-1/2 SAE THRDS, LDPE RED 1-1/2"
35.7
1.405
11.7
0.460
47.1
1.854
1100 220 22
PIP1625RD1 Bouchons filetés à pose facile - PUSH IN PLUG FOR 1-5/8 SAE THRDS, LDPE RED 1-5/8"
38.7
1.525
11.7
0.460
50.3
1.982
1000 200 20
PIP1750RD1 Bouchon plastique clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 1-3/4 SAE THRDS, LDPE RED 1-3/4"
41.9
1.650
11.7
0.460
53.8
2.117
800 160 16
PIP1875RD1 Bouchon clipsable taraudage SAE/NPT - PUSH IN PLUG FOR 1-7/8 SAE THRDS, LDPE RED 1-7/8"
45.1
1.775
11.7
0.460
56.3
2.216
800 160 16
Référence Description Filets NPT SAE... Diamètre
mm
po
Longueur
mm
po
Ø coll.
mm
po
Boite/Minipack/Protopack
Qté
Voir prix / Acheter
Légende:
- Ajouter au panier - Acheter maintenant - Voir le Prix

Les Packs Protos ne sont disponibles qu’en ligne.


Incertain sur le type de protection requise pour votre besoin?
Vous pouvez consulter le guide d'application
MOCAP vous propose la vente de capuchons de toutes sortes. Ils répondront à vos besoins.

Spécialiste du bouchon en plastique, MOCAP est fabricant de bouchons de protection, MOCAP est fabricant, de bouchons en silicone. Le groupe vous propose l’achat et la vente de bouchons en plastique ainsi que toute une gamme de produits tels que la pastille haute température, le capuchon en vinyle et le ruban autosoudant.



Bouchon obturateur taraudage SAE et NPT - Informations

Les bouchons obturateur série IP sont conçus pour une insertion facile dans les trous taraudés normalisés SAE et NPT par simple clipsage.
L'aspect finition, en plus de la protection même, sera un plus.

Ils protégeront des moisissures, poussières et dommages éventuels durant la production, transport ou stockage.
La série PIP est disponible en rouge en polyéthylène pour taraudages SAE de 1/4" à 1-7/8" ou NPT de 1/8" à 1".

MOCAP dispose des bouchons obturateurs normes SAE et NPT pour vos besoins immédiats.

Tous les références sont disponibles par boîte standard ou minipak.







RoHS


Diagramme
MOCAP - Taraudages NPT et SAE
